Hornady reloading dies represent the finest in machined craftsmanship. Articulated details offer more precise reloading, by offering easier adjustments, better alignment and smoother functioning.
IF YOU ARE UNABLE TO FIND YOUR CALIBRE NEEDED, ORDER THE BLANK DIE AND POP IN THE NOTES THE CALIBRE YOU REQUIRE.
What makes Hornady dies better?
Hornady reloading dies represent the finest in machined craftsmanship. Articulated details offer more precise reloading, by offering easier adjustments, better alignment and smoother functioning. With one of the finest internal finishes in the industry, Hornady Custom Grade and Match Grade Dies provide a lifetime of reloading. They're so well crafted that they're guaranteed never to break or wear out from normal use.
Zip Spindle™ Design
The Zip Spindle™ design on all full length size dies positively locks to eliminate slippage. A series of light threads cut on both the spindle and spindle collet allows you to make incremental adjustments by turning the spindle or you can easily “zip it” up or down for larger movements.
Smooth Finish
Internal die profile is precision machined and polished to a smooth finish that delivers reliable functioning without case sticking or excessive friction. Our pistol dies feature a titanium nitride “gold ring” finish that’s harder than carbide and doesn’t require lubrication. The super hard coating is perfect for resizing soft pistol brass and won’t scratch your cases.
Lock Rings with Wrench Flats
The Hornady Sure-Loc™ lock rings clamp around the entire die applying constant pressure across the threads to hold the ring in place. The locking screw tightens the ring without ever coming into ontact with the threads, eliminating possible damage from pliers.
Elliptical Expander
Superior to “ball expanders,” this Hornady exclusive provides extremely smooth neck sizing and significantly reduces friction and case neck stretch. Internal threading prevents it from pulling loose and the elliptical expander also eliminates the need for a separate expander die for necking-up to the next caliber.
Seater Adjustment Screw
Seater adjustment screw easily adjusts for bullet seating depths.
Compression Washer
This washer provides the necessary tension to make fine adjustments easier, and keep the die set in place.
Retainer Ring
Locking retainer spring removes in seconds for easy disassembly and cleaning of the die.
In-line Bullet Seating System
Our seating system holds the bullet, the case neck and the seating stem in perfect alignment in the sleeve BEFORE the bullet enters the neck of the case. The system includes a floating bullet alignment sleeve, a floating steel seating stem and a built-in crimper for benchrest precision. Bullets are aligned in the sleeve as they enter the die for optimum seating and enhanced accuracy.
Built-in Crimper
The built-in crimper gives you the option of crimping without the need for an extra crimp die thus saving a station on your press.
Taper Crimp Seating Die
The intuitive design of this die allows seating and taper crimping to be completed in one step, eliminating the need for a separate taper crimp die. Available in 9MM, 40 S&W & 45 Auto.
Taper Crimp Adjust Screw
Easily adjusts amount of crimp on the cartridge without changing bullet seating depth or loosening the lock ring.
Easy Access Die Boxes
Every Hornady die set comes in a convenient box that’s compartmentalized for dies, bushings, shell holders and a taper crimp die. Stackable and clearly labeled, they offer an organized and clean approach to storing your dies.
Titanium Coated Sizing Ring
Our Straight Wall Sizing Dies feature a titanium coated sizing ring (gold ring). This eliminates case sticking and requires no lubrication. The super hard, smooth coating is used in high-pressure, high-wear tools to reduce abrasion, so it’s perfect for resizing relatively soft pistol brass, and won’t scratch your cases. Less friction also means less wear on cases, for longer case life. Spindle locks in place with collet lock for positive decap and easy adjustment.
Type of product | Seating Dies |
---|---|
Calibre | .223/4 Cal |
Barcode | horn-044127 |
SKU | horn-044127 |
Brand | Hornady Reloading |
FAQ - Frequently Asked Questions
Welcome to our purchasing FAQ! Here you'll find answers to our most asked questions regarding purchasing from us. If you are after Reloading FAQ's, please click HERE, where you can find more specific question and answers. Still can't find quite what you're looking for, or have something we should know? Send us an email, we're happy to help!
-
Q1: Do you ship to my country?
A1: European countries (All items except Ammunition, Powders, Primer, Cases & Projectiles)
-
Q2: How much do I pay for shipping?
A2: The shipping charge will be added to your order and visible on your receipt before you check out. The shipping is based on the destination country. You’ll get free shipping on orders above a certain amount.
Free shipping on orders above: £50 for mainland UK next day deliveries.
France - £25
Norway – £45
Finland – £46
Germany – £25
UK – £5 (Free UK Mainland with purchases over £50)
Rest of the EU – £25-100
Global – £100-200 -
Q3: What are the accepted payment methods?
A3: We accept online card payment with MasterCard, VISA, Worldpay or Bank Direct Debit
-
Q4: What currency do I pay in?
A4: The currencies used are GBP, EUR & USD The currency is chosen automatically depending on your shipping country.
-
Q5: When do I receive my order?
A5: We dispatch all orders in 1-2 business days with DPD & Parcelforce, delivery time will depend on the shipping country and address.
-
Q6: Do I have to pay international taxes and duties?
A6: Your order may be subject to import duties and taxes, which are levied once a shipment reaches your country. We cannot control and is not responsible for any duties/taxes applied to your package upon delivery. You will be responsible for paying additional charges for customs clearance. Customs policies vary widely from country to country; please contact your local customs office for further information.
Rifle Calibre Name | Common Metric Name | Bullet Diameter |
.17 | 4.5mm | .172" |
.204 | 5.2mm | .204" |
.223 | 5.56mm | .224" |
.22 (Rimfire) | 5.6mm | .223" |
.22 (Centrefire) | 5.6mm | .224" |
.243 | 6mm | .243" |
.257 | 6.53mm | .257" |
.260 | 6.5mm | .264" |
.270 | 6.8mm | .277" |
.280 | 7mm | .284" |
.30 | 7.62mm | .308" |
.325 | 8mm | .323" |
.33 | 8.6mm | .338" |
.366 | 9.3mm | .366 |
.375 | 9.5mm | .375" |
.416 | 10.6mm | .416" |
.50 | 13mm | .510" |
